Question 33/46
You have a drawing that contains three of the same objects.
Which object has layer transparency set to 90? Click the correct object in the answer area.
Which object has layer transparency set to 90? Click the correct object in the answer area.
Correct Answer:
Explanation:
According to the AutoCAD for Design and Drafting documents, layer transparency is a property that makes objects on a layer appear translucent or opaque. The higher the transparency value, the more transparent the layer appears. Therefore, the object that has layer transparency set to 90 is the one that appears the most faded or dimmed in the drawing. In this case, it is the object on the right. You can click on it to select your answer.
