Exhibit. A CAD designer is using the AutoCAD Count tool to quantify the number of DR-36 door blocks that are in the drawing. A yellow error alert triangle appears next to the total count for the DR-30 block when selecting the item from the count list as shown in me exhibit. Which oi these conditions would result in the alert tor the block highlighted in red?
Correct Answer: B
* Understanding the Count Tool Alert: * In AutoCAD, the Count tool is used to quantify the number of block instances within a drawing. * A yellow error alert triangle next to the block count indicates an inconsistency or issue with the blocks in the drawing. * Common Reasons for Alert: * The block is on the wrong layer. * The block is exploded. * The block does not have its color assigned to BYLAYER. * The block has a different scale factor. * Identifying the Issue: * Option A: The block being on the wrong layer does not typically trigger a count alert. * Option C: The color assignment to BYLAYER does not affect the block count. * Option D: Different scale factors usually do not trigger a count alert unless the block definition is altered. * Option B: Exploded blocks result in losing the block definition, causing AutoCAD to alert the user of incomplete blocks, which matches the scenario depicted in the exhibit. * Conclusion: * The alert is due to the block being exploded, resulting in a mismatch between the expected block * count and the actual block instances recognized by AutoCAD. References: * AutoCAD Help Documentation on Block Counting and Alerts. * User manuals and community forums discussing common issues with block counts.
