Explanation:
Network Types and Corresponding Link Layer Protocols
* Broadcast: Ethernet
* Point-to-Point (P2P): PPP, HDLC
* Point-to-Multipoint (P2MP): PPP
* Non-Broadcast Multi-Access (NBMA): Frame Relay
OSPF Network Types:OSPF classifies networks based on link layer protocols into the following types:
* Broadcast: This type assumes that all routers on the network can communicate directly with one another using multicast or broadcast frames. Ethernet networks are typical examples.
* Point-to-Point (P2P): This type is used for links that connect two routers directly. Common protocols include PPP (Point-to-Point Protocol) and HDLC.
* Point-to-Multipoint (P2MP): This type simulates multiple point-to-point connections over a single physical network, often used in WAN scenarios where PPP is employed.
* Non-Broadcast Multi-Access (NBMA): These networks connect multiple devices but lack native broadcast capability, such as Frame Relay.
