Configuration Analysis:
* On R2, the following configuration has been applied:
acl 200
rule deny source 10.1.0.0 0.0.3.0
rule permit
#
ospf 1
filter-policy 2000 import
* This configuration uses ACL 200 to filter routes during import into the OSPF routing table on R2.
* Rule deny source 10.1.0.0 0.0.3.0: Blocks routes in the range 10.1.0.0/24 to 10.1.3.0/24 (inclusive).
* Rule permit: Allows all other routes to be imported.
* Impact of ACL 200 on Route Import:
* 10.1.0.0/24 to 10.1.3.0/24: These subnets are explicitly denied by ACL 200 and will not appear in R2's routing table.
* 10.1.4.0/24 and beyond: These subnets are permitted by the rule permit statement and will be imported into R2's routing table.
* Routing Table Entries on R2:
* Option A (10.1.4.0/24): Exists in R2's routing table because it is permitted.
* Option B (10.1.3.0/24): Does not exist because it is denied by ACL 200.
* Option C (10.1.2.0/24): Does not exist because it is denied by ACL 200.
* Option D (10.1.1.0/24): Does not exist because it is denied by ACL 200.
* A (10.1.4.0/24)
Correct Options:References:
* HCIA-Datacom Study Guide, Chapter: OSPF Route Filtering
* Huawei ACL Configuration for Route Policies
