(Ticket 14: EIGRP Passive Interface)
Scenario: The implementation group has been using the test bed to do a 'proof-of-concept' that requires both Client 1 and Client 2 to access the WEB Server at 209.65.200.241. After several changes to the network addressing, routing schemes, DHCP services, layer 2 connectivity, FHRP services, and, device security, a trouble ticket has been opened indicating that Client 1 cannot ping the 209.65.200.241 address.

Figure 1

Figure 2
Use the supported commands to isolate the cause of this fault and answer the following questions.
Configuration on R4
Configuration on DSW1
router eigrp 10
network 10.1.4.4 0.0.0.0
network 10.2.1.1 0.0.0.0
network 10.2.4.13 0.0.0.0
no auto-summary
Configuration on DSW2
router eigrp 10
network 10.1.4.8 0.0.0.0
network 10.2.2.1 0.0.0.0
network 10.2.4.14 0.0.0.0
no auto-summary
Configuration on R4
router eigrp 10
passive-interface default
redistribute ospf 1 route-map OSPF->EIGRP
network 10.1.4.4 0.0.0.3
network 10.1.4.8 0.0.0.3
default-metric 10000 100 255 1 10000
no auto-summary
What is the solution to the fault condition?
