To temporarily remove a node with a specific serial number from the VxRail cluster, follow these steps:
* Log in to vSphere Client:
* Open the vSphere Client.
* Enter the username:[email protected].
* Enter the password:VMw@r3!123.
* ClickLogin.
* Identify the Node with Serial Number "V0730040000000":
* In the vSphere Client interface, navigate to theHosts and Clustersview.
* Expand theVxRail-DCand then theVxRail-Cluster.
* Locate the Node:
* Click on each host
(e.g.,vcluster730-esx01,vcluster730-esx02,vcluster730-esx03,vcluster730-esx04) and check the Summary tab to identify the node with the serial numberV0730040000000.
* The Summary tab provides details about the hardware, including the serial number.
* Put the Node in Maintenance Mode:
* Right-click on the identified node.
* SelectMaintenance Mode>Enter Maintenance Mode.
* SelectEnsure Accessibilityand clickOK.
* Remove the Node from the Cluster:
* Once the node is in maintenance mode, right-click the node again.
* SelectRemove from Inventory.
* Confirm the action by clickingYesorOKwhen prompted.
* Verify the Node Removal:
* Ensure that the node is no longer listed under theVxRail-Cluster.
* Check the overall health and status of the cluster to confirm that it is functioning properly without the removed node.
Reference:
Dell VxRail Administration Guide: VxRail Administration Guide
=========================
Note: Be cautious when removing nodes from a VxRail cluster, as this can impact the cluster's capacity and redundancy. Always follow proper procedures and consult with Dell Support as needed.
