Question 28/159

SIMULATION
SWITCH.com is an IT company that has an existing enterprise network comprised of two layer 2 only switches; DSW1 and ASW1. The topology diagram indicates their layer 2 mapping. VLAN 20 is a new VLAN that will be used to provide the shipping personnel access to the server. Corporate polices do not allow layer 3 functionality to be enabled on the switches. For security reasons, it is necessary to restrict access to VLAN 20 in the following manner:
Users connecting to VLAN 20 via portfO/1 on ASW1 must be authenticated before they are given

access to the network. Authentication is to be done via a Radius server:
Radius server host: 172.120.40.46

Radius key: rad123

Authentication should be implemented as close to the host as possible.

Devices on VLAN 20 are restricted to the subnet of 172.120.40.0/24.

Packets from devices in the subnet of 172.120.40.0/24 should be allowed on VLAN 20.

Packets from devices in any other address range should be dropped on VLAN 20.

Filtering should be implemented as close to the serverfarm as possible.

The Radius server and application servers will be installed at a future date. You have been tasked with implementing the above access control as a pre-condition to installing the servers. You must use the available IOS switch features.

Correct Answer:

Here is the solution below:
Explanation/Reference:
The configuration:
Step1: Console to ASW1 from PC console 1
ASW1(config)#aaa new-model
ASW1(config)#radius-server host 172.120.39.46 key rad123
ASW1(config)#aaa authentication dot1x default group radius
ASW1(config)#dot1x system-auth-control
ASW1(config)#inter fastEthernet 0/1
ASW1(config-if)#switchport mode access
ASW1(config-if)#dot1x port-control auto
ASW1(config-if)#exit
ASW1#copy run start
Step2: Console to DSW1 from PC console 2
DSW1(config)#ip access-list standard 10
DSW1(config-ext-nacl)#permit 172.120.40.0 0.0.0.255
DSW1(config-ext-nacl)#exit
DSW1(config)#vlan access-map PASS 10
DSW1(config-access-map)#match ip address 10
DSW1(config-access-map)#action forward
DSW1(config-access-map)#exit
DSW1(config)#vlan access-map PASS 20
DSW1(config-access-map)#action drop
DSW1(config-access-map)#exit
DSW1(config)#vlan filter PASS vlan-list 20
DSW1#copy run start
