Diffie-Hellman Key Exchange Mechanism
The
Diffie-Hellman
key exchange uses the public/private key pair to generate
a secret key. This process is illustrated in Figure below.

6
In step 1, users exchange public keys. When you're using asymmetric
encryption, the exchange of public keys is all that is required to begin encrypting. But Diffie-Hellman combines asymmetric and symmetric processes.
Each user's private key is combined with their encrypting partners'
public key using the Diffie-Hellman key calculation, as shown in step 2. As we stated earlier, the public and private keys that each user creates are mathematically related; that's how the users can exchange keys, apply the Diffie- Hellman key calculation, and both end up (in step 3) with mathematically identical keys.
Different mathematical groups can be used to generate the identical keys. The Diffie-Hellman standard supports three groups: DH groups 1, 2, and 5. The larger the group number, the larger the prime number used to generate the key pair. The larger groups are more secure but require more CPU cycles to generate the keys. Check Point also gives you the ability to expand the database of groups by adding custom groups.
The process depicted in Figure above solves two problems. First, you have generated the secret key necessary to perform symmetric encryption without having to physically exchange the secret key with your encrypting partner.
Second, you can use that key to symmetrically encrypt data much more
quickly than you can using asymmetric encryption alone. The best aspects of both encryption techniques are combined to yield a process that's better than each individual technique.The encryption processes we've described fill out the P in PAIN, but they are useless unless you get the correct key from your encrypting partner. The next section addresses how to verify that the key is from the correct source and explains theAINin PAIN
