Explanation/Reference:
Explanation:
The Hyper-V PowerShell module has several aliases so that checkpoint and snapshot can be used interchangeably.
Virtual machine snapshots are file-based snapshots of the state, disk data, and configuration of a virtualmachine at a specific point in time.
You can take multiple snapshots of a virtual machine, even while it is running.
You can then revert the virtual machine to any of the previous states by Applying a snapshot to the virtualmachine.
Taking a snapshot of a VM is to in essence freeze the current state and make it a parent disk based on currentstate, and at the same time create a child disk to capture all subsequent changes. -See more at:
Snapshots require adequate storage space.
Snapshots are stored as .avhd files in the same location at the virtual hard disk.
Taking multiple snapshots can quickly consume a large amount of storage space.
When you use Hyper-V Manager to delete a snapshot, the snapshot is removed from the snapshot tree but the .avhd file is not deleted until you turn off the virtual machine.

References:
http://www.laneolson.ca/2009/10/09/hyper-v-snapshots-and-disk-space/
http://blogs.technet.com/b/yungchou/archive/2013/01/23/hyper-v-virtual-hard-disk-vhdopertions- explained.aspx
http://zoom.it/12u8
http://www.server-talk.eu/wp-content/uploads/article_2010-05-28_02.png
http://blogs.msdn.com/b/virtual_pc_guy/archive/2009/04/15/what-happens-when-i-delete-asnapshot-hyper- v.aspx
http://blogs.technet.com/b/yungchou/archive/2013/01/23/hyper-v-virtual-hard-disk-vhd-operations- explained.aspx
http://blogs.technet.com/b/josebda/archive/2012/03/20/windows-server-8-beta-hyper-vover-smb- quickprovisioning-a-vm-on-an-smb-file-share.aspx
https://docs.microsoft.com/en-us/virtualization/hyper-v-on-windows/user-guide/checkpoints
http://blogs.technet.com/b/josebda/archive/2012/03/20/windows-server-8-beta-hyper-vover-smb- quickprovisioning-a-vm-on-an-smb-file-share.aspx
https://docs.microsoft.com/en-us/virtualization/hyper-v-on-windows/user-guide/checkpoints
