Question 71/95

Refer to the exhibits.

A network administrator is setting up MPLS Layer 2 VPN connections between several customer sites:
Connection 1 = Customer Site 1 to customer Site 2
Connection 2 = Customer Site 1 to customer Site 3
The administrator has established two pseudowires (PW) on PE-1, as shown in the exhibit. On PE-1, interface GigabitEthernet1/0/1 connects to CE-1 at Site 1. Which setup establishes the desired connections?

A. CE-1 sends traffic to PE-1 G1/0/1 in VLAN 10 and VLAN 20. PE-1 has two services instances on G1/0/1. One instance encapsulates VLAN 10, and PW1 is bound to it. The other instance encapsulates VLAN 20, and PW2 is bound to it.

B. PE-1 has two policy-based routing (PBR) policies, each of which selects traffic destined to Site 2 or Site
3. The appropriate policy is applied to the PW for each connection.

C. CE-1 implements MPLS. It establishes two PWs with PE-1. PE-1 now has four PWs. PE-1 maps the PW3 out label to the PW1 in label. It maps the PW4 out label to the PW2 in label.

D. CE-1 assigns VLAN 10 to VPN instance 1 and VLAN 20 to VPN instance 2. PE-1 places G1/0/1 in both VPN instances 1 and 2. PE-1 associates VPN instance 1 with PW1 and VPN instance 2 with PW2.

Correct Answer: A

Explanation/Reference:
Use display l2vpn pw to display PW information.
service-instance is one customer service being served on the port, you can consider the number behind
"service-instance" command as local identifier on the port, it doesn't have to match on the other side.
Example configuration:

Syntax Explanation:
service-instance is one customer service being served on the port, you can consider the number

behind "service-instance" command as local identifier on the port, it doesn't have to match on the other side.
encapsulation s-vid 10, this command specifies which vlan tagged traffic is to be taken and transported

to the other side of this L2 tunnel.
xconnect peer 4.3.2.1 pw-id 1222 is telling the router to what remote LDP peer the L2 VLL should go to

and a unique pw-id (PseudoWire ID) that has to match on both ends and is unique identifier of the tunnel.
Note: A pseudowire (or pseudo-wire) is an emulation of a point-to-point connection over a packet-switching network (PSN).
References: http://networkgeekstuff.com/networking/l2-mpls-vllsvpls-overview-including-martinikompella- mode-h3c-configuration-examples/
