Explanation/Reference:
Explanation:
Parameter-MapHere is the configuration for the Parameter-Map. This section provides insight on the how to configure the Virtual IP address on the WLC and how to set the parameter type, which helps to specify the redirect URL, Login Page, Logout page, and Failure page. You must make sure that the flash has these files.
parameter-map type webauth globalvirtual-ip ipv4 1.1.1.1parameter-map type webauth customtype webauthredirect on-success http://www.cisco.combanner text ^C CC global ip for redirect ^C custom-page login device flash:webauth_login.html custom-page success device flash:webauth_success.html custom- page failure device flash:webauth_failure.html custom-page login expired device flash:webauth_expired.html Wireless LAN (WLAN) ConfigurationHere is the configuration for WLAN. The WLAN is configured for Layer
3 security. This configuration maps the authentication list to Local_webauth and ensures that the authentication is handled by the local net users. This calls the AAA configuration that is in the initial step.
wlan webauth 1 webauthclient vlan Vlanxno security wpano security wpa akm dot1xno security wpa wpa2no security wpa wpa2 ciphers aessecurity web-authsecurity web-auth authentication-list local_webauthsecurity web-auth parameter-map customsession-timeout 1800no shutdown Reference:http://www.cisco.com/c/en/us/support/docs/wireless/5700-series-wireless-lan- controllers/117728-configure-wlc-00.html
