Question 13/65
You have three servers that run Windows Server 2016. The servers are connected as shown in the exhibit.
On all the servers. Windows Firewall is configured to allow ping traffic.
You start Routing and Remote Access Service (RRAS) on Server2.
You need to identify which IP addresses you can ping successfully from Server1 and Server3.
What should you identify? To answer, select the appropriate options in the answer area.
On all the servers. Windows Firewall is configured to allow ping traffic.
You start Routing and Remote Access Service (RRAS) on Server2.
You need to identify which IP addresses you can ping successfully from Server1 and Server3.
What should you identify? To answer, select the appropriate options in the answer area.
Recent Comments (The most recent comments are at the top.)
The correct answer is:
From Server1, you can successfully ping: 172.16.0.1 and 10.10.0.1 only
From Server3, you can successfully ping: 10.10.0.1 only
Server 1 is able to send queries to other subnets, because he has a gateway to Server2. Server2 is able to send a reply back from it's 10.10.0.1 NIC.
Server1 is NOT able to receive answers from Server3, because server3 does not know the route back to Server1. So, when Server1 sends a ping packet to the ip address ip Server3, it will be routed by Server2, will be received by Server3, but Server3 will not be able to answer it because the route back to Server1 is unknown.
Server3 does not have a gateway and therefor is only able to ping ip addresses in it's own subnet.
