Question 17/35

Referring to the exhibit, R1 and R2 are QFX5100 Series devices acting as VXLAN Layer 2 Gateways using PIM-SM signaling for the same VXLAN segment (VNI 5100). The multicast group assigned to VNI 5100 is
239.0.0.1. R1 currently has an entry in its MAC table for Host B.
In this scenario, how will R1 react to receiving the Ethernet frame from Host A?

A. R1 will send a VXLAN encapsulated Ethernet frame using 10.1.1.1 as the destination address.

B. R1 will send a VXLAN encapsulated Ethernet frame along the source-based multicast tree using
239.0.0.1 as the destination address.

C. R1 will send a VXLAN encapsulated Ethernet frame using 10.2.2.2 as the destination address.

D. R1 will send a VXLAN encapsulated Ethernet frame along the RP-based multicast tree using 239.0.0.1 as the destination address.

Correct Answer: A

Explanation/Reference:
Explanation:
Host A and B are on the same subnet, so communicating at Layer 2 - MAC to MAC. The Layer 3 information is for VXLAN mapping to multicast groups - so the destination address is 239.0.0.1 group, and the tree is source-based (R1 has (10.1.1.1,239.0.0.1) in its multicast table). Assumption here the question infers Host A is sending a frame to Host B Question poorly worded.
