Question 105/117

Refer to the exhibit. An engineer must configure a FlexVPN site-to-site GRE tunnel that uses IPsec between two Cisco routers. The indicated configuration was applied on Router_A, but the tunnel fails to come up. Which IP address must be set on Router_A to resolve the issue?

A. 192.16.1.1

B. 192.16.1.2

C. 192.168.10.1

D. 192.168.10.2

Correct Answer: B

The configuration snippet on Router_A shows an IKEv2 keyring entry for Router_B with the following line:
peer Router_B
address 127.0.0.1
pre-shared-key Cisco4512!
The issue is that 127.0.0.1 (loopback address) is incorrectly used as the peer address, which prevents IKE negotiation.
In a FlexVPN site-to-site GRE tunnel over IPsec, the peer address must be set to the public IP address of the remote router. In this case, Router_B's public IP address is 192.16.1.2.
