Question 68/151

Refer to the exhibit. A network engineer must design a BGP solution based on:
- The route reflector must have one or more direct physical connections to the core routers (R3 and R4).
- The route reflector must have full redundancy and avoid a single
point of failure.
- R2 to R1 link utilization is 90%, and the remaining links are less
than 50% utilized.
Which two solutions must the design include? (Choose two.)

A. Configure R1 to be a client of R2 and R4.

B. Configure R5 to be a client of R3 and R4

C. Configure R2 to be a client of R1 and R4.

D. Configure R3 to be a client of R2 and R4.

E. Configure R4 to be a client of R1 and R3.

Correct Answer: D,E

We want to try and centralize our Route Reflector, in this example all routers qualify to be Route Reflectors because they have at least 1 link connected to R3/R4 the core Routers.
- We want to try avoid link between R1 and R2 because it's caping at 90%.
- Answer A uses the link that's 90%
- Answer B is not a centralize location, R5 is way down there.
- Answer C utilize the link that's at 90%
- D & E both have redundancy and do not use the link that has 90% and it's centralized.
