Instructions
Enter CLI commands on the ASA and Branch router to verify network operation and answer the

multiple-choice questions.
THIS TASK DOES NOT REQUIRE DEVICE CONFIGURATION.

Click on the devices or the lower menu bar to gain access to the console of that device. No console or

enable passwords are required.
Not all CLI commands are available for this exercise.

To access the multiple-choice questions, click on Questions tab and then the numbered boxes on the

left of the panel to view each question.
There are four multiple-choice questions with this task. Be sure to answer all four questions before

selecting the Next button.
Scenario:
You are the senior network security administrator for your organization. Recently and junior engineer
configured a site-to-site IPsec VPN connection between your headquarters Cisco ASA and a remote
branch office.
You are now tasked with verifying the IKEvl IPsec installation to ensure it was properly configured
according to designated parameters. Using the CLI on both the Cisco ASA and branch ISR, verify the
IPsec configuration is properly configured between the two sites.
NOTE: the show running-config command cannot be used for this exercise.
Topology:



What is the name of the transform set being used on the ISR?
